FR DST 201 2 IN 1 OSCILLOSCOPE

The FR DST-201 / FNIRSI DST-201 is a compact, portable 2-in-1 handheld device combining an oscilloscope + multimeter + signal generator (in some variants, 3-in-1) — ideal for makers, field technicians, and electronics hobbyists. With a 2.8-inch color TFT screen, rotary selector knob, and versatile measurement modes, it gives you the convenience of multiple tools in one lightweight unit. Key Features Oscilloscope mode: • Analog bandwidth: 1 MHz • Sampling rate: ~ 5 MSa/s • Input protection: up to ±400 V • Vertical sensitivity: from 10 mV/div to 10 V/div (on X1 setting) • Time base: from ~500 ns/div to 20 s/div • Trigger modes: Auto / Normal / Single; rising & falling edge Signal generator (DDS) mode: • Supports ~ 13 waveform types • Frequency range: 0 to 10 kHz • Output voltage adjustable: 0 to 3.0 V Multimeter & measurement functions: • Measures AC/DC voltage, current, resistance, capacitance, frequency, temperature, diode/continuity, etc. • Auto-measurement mode, data hold, live-wire detection, overload protection, low battery warnings Display & user interface: • 2.8-inch TFT color screen, with adjustable backlight • Rotary function knob to switch measurement modes quickly • Compact, portable, suits bench or field work Power & battery: • Built-in rechargeable battery (3000 mAh) • Long standby / operation time (specs suggest ~15 hours standby)

• Availability: 50 In Stock
• Model: FR DST 201 2 IN 1 OSCILLOSCOPE
