Products Details of UNI-T UT-Z002 Macro Lens for Thermal Camera UTi260B UTi120B UTi165B for PCB Circuit Board Repair & Electronics Fault Diagnosis
UNI-T UT-Z002 Macro Lens / Thermal Camera Accessory – Specifications
Specification | Details |
Product Type | Macro Lens / Thermal Camera Accessory |
Brand Name | UNI-T |
Model Number | UT-Z002 |
Compatible Devices | UTi260B, UTi720A |
Lens Type | Infrared Macro Lens |
Application | Mobile Phone Repair, PCB Inspection, Circuit Analysis |
Installation Method | Snap-on / Clip-on |
Material | Plastic + Optical Germanium Lens |
Main Material | Plastic |
DIY Supplies | Electrical |
Data Record Function | No |
Electronic | No |
Semi-finished Product | No |
High-concerned Chemical | None |
Certification | CE, RoHS |
Origin | Mainland China |
Keywords | UNI-T UT-Z002 Macro Lens, Thermal Camera Macro Lens, Infrared Imager Lens |
Key Features
- Designed for close-range thermal imaging inspection.
- Compatible with UNI-T UTi260B and UTi720A thermal cameras.
- Uses a high-quality optical germanium lens for infrared imaging.
- Ideal for mobile phone motherboard repair, PCB diagnostics, and electronic circuit analysis.
- Easy snap-on / clip-on installation without tools.
- Enhances thermal camera performance for viewing small electronic components and fine details.
Description
UNI-T UT-Z002 Macro Lens for Thermal Camera UTi260B UTi120B UTi165B, HD Infrared Close-up Lens for PCB Circuit Board Repair & Electronics Fault Diagnosis
Unlock Micro-Level Thermal Vision for Your UNI-T Camera with the UT-Z002 Macro Lens!
Struggling to see the heat signature on tiny electronic components? The standard lens on your thermal imager is powerful, but it's not designed for the microscopic world of modern circuit boards.
The UNI-T UT-Z002 Macro Lens is the perfect auxiliary adaptor that transforms your thermal camera into a high-precision diagnostic tool. It allows you to get an incredibly detailed, close-up view of PCBs, helping you to find and fix faults faster than ever before.
Why Choose the UT-Z002 Macro Lens?
- See the Unseen: Ordinary thermal views show you the general area of a problem. Our Macro Lens zooms in on the specific faulty component, whether it's a tiny SMD resistor or a single pin on an IC chip.
- Professional Grade Accuracy: Don't guess. Get high-definition thermal images with reliable temperature data. This is crucial for professional circuit load analysis and ensuring product stability during R&D.
- Built for Speed and Convenience: The clever snap-on design means you can attach or detach the lens in a moment's notice. No screws, no clamps, no hassle.
- A Must-Have for Every Technician: Whether you are in electronics repair, product development, or digital product evaluation, this lens will elevate your capabilities and improve your workflow.
Key Applications & Use Cases
1. For Electronics Repair & Maintenance:
- Task: Quickly identify fault points on a motherboard or circuit board.
- Solution: Use the UT-Z002 to instantly locate hotspots, short circuits, and overheating components. Perfect for mobile phone repair, laptop maintenance, and other PCB inspection tasks. Improve your repair success rate and efficiency.
2. For Product Development & R&D:
- Task: Analyze circuit loads and test heat dissipation on new prototypes.
- Solution: Help R&D personnel visually observe how heat spreads across a board, improve the structural design, and enhance overall product stability and reliability.
3. For Digital Product Evaluation:
- Task: Visually demonstrate heating issues for tech reviews or quality control.
- Solution: The high-definition IR image provides clear, accurate, and undeniable evidence of heating spots and thermal performance, making it a perfect auxiliary tool for professional evaluators.
Guaranteed Compatibility
This UT-Z002 Macro Lens is fully compatible with the following UNI-T Thermal Camera models:
- UTi260B
- UTi120B
- UTi165B
- UTi260A
- UTi720A
What's in the Box?
- 1 x UNI-T UT-Z002 Macro Lens for Thermal Cameras
